Orbea Wild FS M Team

Orbea Wild FS M Team
  • Color: Orange/Black
  • Color: Anthracite Glitter/Black
$8,749.30 - $9,449.30
$12,499.00 - $13,499.00
Size: Select size
Please select options Unavailable


It's time to get moving. Load up your pack for an afternoon ride and start pedaling. Whatever obstacles exist between you and the trails and your Special Places, it's time to run over them. Reclaim access and discover new adventures the way you like—aboard a fun and capable machine that enhances your skills while it extends your range. Conquer steep climbs and push the limits of traction and good judgment on the way back down. Enjoy clever design and sophisticated suspension kinematics, or simply focus on the trail. Wild FS revitalizes your riding and helps you chart new destinations. Take back control—Take back your Wild.

- The new Wild FS geometry is designed to give new riders more comfort and stability—and for more experienced riders, a bike that doesn't hold them back no matter the terrain.
- Slacker Head Angle: Great stability
- Lower Bottom Bracket: Corners naturally
- Longer Cockpit: Room to move while maintaining balance
- Longer Wheel Base: Stability at high speeds
- Steep Seat Angle: Proper pedaling position
- Short Seat Tube: For long dropper posts

160mm Travel
- Some riders use them to climb thousands of meters on huge rides, others weave in and out of bike parks and jumps during their daily adventures. Wild FS is designed to be flexible and accommodate your style.

- Great tuning capability and a progressive leverage rate help suspension ride higher and recover faster. More progression at full travel limits bottom out forces to frame, suspension, and rider.
- The main pivot point on the Wild FS is located to work efficiently with single ring setups and adapted for the greater BB drop associated with 29" wheels. The balance between compliance and efficiency makes for suspension with a huge range of capability.

Vertical Shock
- Wild FS uses a vertical shock mounting position, with the goal of fitting an additional battery while maintaining low standover.

29-Inch Wheels
- For long, fast rides over varied terrain with the greatest versatility, 29" is the clear choice for Wild FS. Wide 2.6" tires offer a bigger contact patch, which means more grip. More knobs are digging into the ground at any one time, increasing cornering and braking traction.


Motor BOSCH Performance CX Cruise BDU480CX
Battery BOSCH Powertube 625Wh Horizontal US BBP295
Display BOSCH Display unit KIOX Black BUI330
Max Assisted Speed 20mph
Charger Compact Charger 2A (100-240V) Worldwide
Frame ORBEA WILD Full Suspension 2020 Carbon 160mm Travel, FRONT TRIANGLE: Carbon, REAR TRIANGLE: Carbon, FiberLink, BATTERY COVER: Carbon, Boost 12x148 Bosch Gen4
Fork Fox 38 Float Factory 160 Grip2 QR15x110 Kashima E-Bike Optimized
Headset OC Key Holder
Rear Shock Fox Float X2 Factory Trunnion 2-Position Adjust Kashima custom tune 205x65mm
Axles Front: 110 x 15mm thru-axle
Rear: 148 x 12mm thru-axle
Rims/Wheels DT Swiss HX-1501 Spline 30c TLR 15/110mm CL
Tires Front: Maxxis Minion DHF 29 x 2.60" 120 TPI FB 3C Maxx Terra Exo+ TR
Rear: Maxxis Minion DHR II 29 x 2.60" 120 TPI FB 3C Maxx Terra Exo+ TR
Crankset PW-NW32-G4
Chain KMC e12 Turbo Silver
Rear Derailleur Shimano XT M8100 SGS Shadow Plus
Cassette/Rear Cogs Shimano CS-M8100 10-51t 12-Speed
Shifters Shimano XT M8100 I-Spec EV
Handlebars Race Face Next R 35 20mm Rise 800mm
Stem Race Face Aeffect R 35mm interface
Brakes Shimano XT M8120 Hydraulic Disc
Pedals Sold separately
Saddle Fizik Aidon 208x145mm manganese rail
Seat Post OC2 Dropper 31.6mm
Accessories & Extras Etherteen Plus Bosch BDU4 32-38t chainguide
Shimano SL-MT500 I-Spec EV remote lockout

* Subject to change without notice.


Part Numbers

Option UPC MPN
Anthracite Glitter/Black / Small/Medium 08434446776571 L61816VY
Anthracite Glitter/Black / Small/Medium (Demo)
Anthracite Glitter/Black / Large 08434446776601 L61818VY
Anthracite Glitter/Black / X-Large 08434446776632 L61819VY
Orange/Black / Small/Medium 08434446776588 L61816VZ
Orange/Black / Small/Medium (Demo)
Orange/Black / Large 08434446776618 L61818VZ
Orange/Black / X-Large 08434446776649 L61819VZ
Grey/Blue / Small/Medium
Grey/Blue / Small/Medium (Demo)
Grey/Blue / Large
Grey/Blue / X-Large
